~ARCHITECTURAL PLANS~ To Build a 10' x 10' Pergola


Includes Exclusive FineHouse  Resources

In addition to these plans, you will gain free access to a wealth of technical information and design resources not available anywhere else.

  • Details to add a Solid Roof to your structure.

  • Learn about adding lighting and electrical to your structure

  • ¬†Additional full size carving templates

  • Specific construction techniques for building a pergola

All of this and much more on our member website, at absolutely no additional cost!



WHAT'S INCLUDED

The size of the 10' x 10' is the distance between column centers, the size of the upper elements is 13' x 13' because all of the upper elements cantilever 18" beyond the column centers.

Included with the design are the following; Foundation plan, front and side elevations, alternate elevations, roof plan, lintel plan, cross-sections, connection details, shop drawings, full-scale templates for a variety of carved ends, a complete material list, and much more. You will receive more than 20 pages of drawings and instructions.

This set of plans will also allow you to apply for a building permit with all of the drawings required by most jurisdictions but does not include an engineer or architect's seal, this must be obtained locally if required.

These plans are provided as a PDF in 11x17 format with a license to build one structure.

Below is just a sample of the pages you will receive.
